They also have a turned down bolt handle.
The purpose of this set screw is to keep pressure on the 4-40 socket head screws so they can’t back out. Argentina Model 1891 Cavalry Carbine- Lowe Carbina de Caballeia Modelo 1891 Manufactured from 1891 to 1896 when Lowe and three other companys merged to become DMW Model 1891 Cavalry Carbine- DWM These two carbines are fully stocked and have a forend cap with ears to protect the front sight. Put the 10-32 x ? set screw down through the tapped hole in the top of the mount and tighten against the receiver. Lightly tighten the (2) 4-40 socket head screws. Put the 10-32 x 3/8 flat head screw through the mount and into the nut & tighten. Put in the (2) 4-40 x ? socket head screws. It is very important that these holes line up to keep from damaging the threads when the screws are installed. Place the mount over the special nut & align the 4-40 tapped holes in the mount up with the holes in the side of the receiver.
#1891 ARGENTINE MAUSER BOLT REMOVAL FULL#
Slide the flange nut into the undercut at the front of the sight where the spring was with the full radius on the nut toward the rear. Remove the flip up sight & then the spring by first taking the small screw that holds the spring in place, slide it forward and lift it out. Push the pin out at the rear of the rear flip sight. Remove the receiver & barrel from the wood. INSTRUCTION SHEET FOR THE ARGENTINE 1891 #ARG80 S&K manufactures all of their scope mounts here in PA with the best USA materials available. S&K Scope Mounts LLC supports American made. A nifty way to scope your treasured gun without drilling or tapping. A long eye relief scope (Not Included) is required for a scout mount. Outfit your old military rifle with a scope mount and long eye relief scope for better accuracy, longer ranges, more confidence, and more fun hunting or on the range!Ĭheck out S&K’s line of scout mounts available for ex-military guns! These mounts do not require any alterations to the rifle, just removal of the iron sights.
These mounts are made with high quality materials and backed by S&K Scope Mounts. Didn’t think it was possible to easily put a scope and mount on your old 1891 Argentine Scout Mount without drilling and tapping? It is now with high quality, made in the USA scope mounts from S&K.
